Barmesa Pumps - BSP3CCE3-BF - 62030102 - 1.5HP, 1PH, 230/460V, 1.5" X 1.5" Bronze Fitted Self Priming Close-Coupled Pump w/ ODP Enclosure

Barmesa Pumps - BSP3CCE3-BF - 62030102 - 1.5HP, 1PH, 230/460V, 1.5" X 1.5" Bronze Fitted Self Priming Close-Coupled Pump w/ ODP Enclosure

Key features:

• Suction & Discharge: 1½" NPT, female.
• Spherical solids handling: 3/8"
• HP: 1.5
• RPM: 3500
• Impeller: open, trash type, dynamically balanced. Cast iron ASTM A-48, Class 30.
• Shaft: 416 series stainless steel
• Motor: ODP or TEFC, C-face, footed, squirrel cage induction, Class B or F insulation. Single phase, 230/460 V, 60 Hz.
