Zoeller Pump Company - 84-0001 - M84 115V/1Ph/cCSAus/.5 Hp/Cast Iron

Zoeller Pump Company - 84-0001 - M84 115V/1Ph/cCSAus/.5 Hp/Cast Iron

PRODUCT DETAILS

The industry’s only automatic, reversing grinder pump is designed to pump raw sewage in a sewage ejector application.  Solids are cut into a slurry using the industry proven The "Old Faithful" series of pedestal sump pumps is designed for use in indoor residential or light commercial dewatering applications and can be used to transfer groundwater. The pump is designed so that the motor is mounted above the pit cover where it is protected from water, water spray and high humidity. It can be used in containers as small as 18" x 22" (46 x 56 cm). They are extremely useful for transferring unwanted water away from building foundations, basements, and work areas. Each pump is built using noncorrodible materials ensuring a long service life. The top of the pump housing is designed to serve as a strainer capable of passing lint and small solids. The chemically-resistant polyethylene float operates a positive displacement switch with a 12" (30 cm) adjustable cycle. As with every Zoeller pump, each one is 100% factory tested to ensure quality and reliability for years of trouble-free performance! This attention to detail is an inherent feature of every pump in this series, making it one of the best in the industry.

Features:

• Metal enclosed, split phase motor, permanently lubricated, thermal overload protected
• Heavy-duty thermoplastic or cast iron constructed pump housing and base
• Top intake strainer is part of pump housing, passes lint
• No strainer to deteriorate, replace or periodically clean
• Models 82 and 84 - 1½” FPT discharge
• High-impact, PVC (1½” OD) column
• Non-corrosive shaft
• Reliable positive-displacement switch
• Chemically-resistant, polyethylene float
• Plated steel float rod
• Nylon guide
• Permanently-lubricated upper sleeve bearing
• Durable lower bronze bushing
• Adjustable 12” cycle, factory set at 9” (22.8 cm)
• Max. on: 16” (41 cm)
• Min. off: 4” (10 cm)
• Temperature rating: 130°F (54°C)
• Minimum pit size recommended: 18” x 22” (45.7 x 55.8 cm)
• Model 84: Cast iron, 1/2 HP
