Little Giant - WS50HM-12-20 - 620220

This 1/2 hp pump is ideal for dewatering, water transfer, effluent, and wastewater removal. Designed for hi-torque with automatic reset, this pump includes a cast iron motor and pump housing, a solids-handling non-clog impeller, stainless steel heat-treated shaft, and 130 GPM.

Features:

• 1/3 hp, 1/2 hp, or 1hp oil-filled motor with overload protection
• Designed for hi-torque with automatic reset
• Cast iron motor and pump housing
• Solids handling non-clog impeller
• Stainless steel heat-treated shaft
• Double ball bearing and mechanical carbon/ceramic seal
• Piggyback mechanical float option available for automatic operation
• cCSAus listed

Tech Specs:

• HP: 1/2hp

• Frequency: 60Hz

• Phase: Single-Phase

• Amps: Full Load 9.7A

• Amps: Starting 32.6A

• Volts: 208/230VAC

• Cord Length: 20ft

• Motor Type: Submersible

• Continuous Duty: Yes

• Thermal Overload Protection: Yes

• Shut-Off: 63ft

• Max Solid Handling Size: 0.75"

• Switch Type: Manual

• Motor Cooling: Oil
