Little Giant - WS102M-12 - 620203

The WS Series submersible sewage pump from Little Giant is specifically engineered to handle the tough, demanding effluent and sewage waste transfer tasks with high efficiency and long-term dependability. For use in residential, commercial, industrial, and agricultural applications with light to medium transfer demands. Applications include dewatering, effluent waste, wastewater, and sewage handling, where such materials must be moved upward from a collection area to sewer, septic lines, or drainage areas. Little Giant's WS102M-12 is a 1hp sewage pump, 208-230V with a 20' cord, manual operation, and designed to handle 2" solids.

Features:

• 1 HP motor with overload protection
• Designed for continuous duty
• Designed for hi-torque with automatic reset
• Cast iron motor and pump housing
• 416 Stainless steel motor shaft
• upper and lower ball bearings
• Mechanical carbon/ceramic shaft seal
• Handles 2" solids
• cCSAus Listed

Tech Specs:

• HP: 1hp
• Frequency: 60Hz
• Phase: Single-Phase
• Amps: Full Load 9.8A
• Amps: Starting 26.7A
• Volts 208/230VAC
• Cord Length: 20 ft
• Motor Type: Submersible
• Continuous Duty: Yes
• Thermal Overload Protection: Yes
• Shut-Off: 37ft
• Minimum Head: 5ft
• Max Solid Handling Size: 2"
• Switch Type: Manual
• Motor Cooling: Oil
