Barmesa Pumps - 4BWSE302DS - 62170159 - 3HP, 1PH, 60Hz, 230V, 1750RPM, 40' Cord Manual Operation 4" Dual Seal Submersible Solids Handling Pump

Barmesa Pumps - 4BWSE302DS - 62170159 - 3HP, 1PH, 60Hz, 230V, 1750RPM, 40' Cord Manual Operation 4" Dual Seal Submersible Solids Handling Pump

Key features:

• Discharge: 4", 125 lb, flange horizontal.
• Spherical solids handling: 3"
• HP: 3
• RPM: 1750
• Impeller: 2 vane, open, with vanes on back side. Cast iron ASTM A-48, Class 30.
• Shaft: 316 series stainless steel
• Motor: NEMA B, single-phase with permanent split capacitor, 230 V, 60 Hz, oil filled, with Class F insulation. Requires overload protection to be included in control panel.
