Zoeller Pump Company - 384-0046 - GX284 3F/460V/3Ph/Ex Pr

Zoeller Pump Company - 384-0046 - GX284 3F/460V/3Ph/Ex Pr

PRODUCT DETAILS

•     Durable cast iron constructed switch case, motor and pump housing, base and impeller
•     No sheet metal parts to rust or corrode
•     All cast iron class 25-30 25000# tensile strength
•     Stainless steel screws, bolts, float rod, handle, guard and arm and seal assembly
•     Shaft seal - Carbon and ceramic rotary face seal, with stainless steel wetted parts
•     Upper sleeve bearing and lower ball bearing running in bath of oil
•     Maximum temperature for sewage or dewatering 130°F (54°C)
•     Oil-filled, hermetically sealed, automatic reset thermal overload protected motor (1 Ph and Auto 3 Ph)
•     Cast iron non-clogging vortex impeller
•     3 Inch Flanged Vertical Discharge
•     All models pass 2" spherical solids
•     Automatic units available with float operated, submersible (NEMA 6) mechanical switch (1 and 3 phase units)
•     Corrosion resistant powder coated epoxy finish
•     On point: 15-1/4"
•     Off point: 5-1/4"
•     Reserve powered design. For unusual conditions a reserve safety factor is engineered into the design of every Zoeller pump.
