Zoeller Pump Company - 31354-0001 - Control,Pivot/Sim/1Ph/115/200/230V/0-20FLA/Standard

Zoeller Pump Company - 31354-0001 - Control,Pivot/Sim/1Ph/115/200/230V/0-20FLA/Standard

PRODUCT DETAILS

An electrical control panel is used on a simplex pump application where automatic electrical cycling of the pump is desired for added protection in residential or commercial applications. A control panel is required for all systems using a nonautomatic pump. The built-in alarm system, a standard feature, will activate when the water level becomes unusually high.

Please note that this control panel requires appropriate size circuit breaker to be installed by electrician.

This control panel can be used with 115/200/230V, single phase pumps between 0 to 20 amps.

    This control panel can be used with Zoeller pumps:

E53         N53         N55         N57        E57        N59         E59        N98       E98

       N137       E137       N139       E139      E140      N140       N161      N161 (361-0023)

       E161       N163       E163       I163        E165      E185       E186      E188      I188

       E189       I189         E264        N264      E266       N266     E267       N267      E268      N268

       E270       N270       E282       N282      N282 (282-0002)      I282       E284      I284         N292

        E293       E293 (393-0004)   I293       E294      E294 (394-0004)     I294       E295      E404      E405

 Features

• NEMA 12" x 10" x 6" with lockable
• For outdoor or indoor use
• Red alarm beacon with 360-degree visibility
• Audible alarm buzzer rated 95 db at 2ft (0.6 m)
• SILENCE/RESET/TEST toggle switch with weatherproof rubber boot
• HAND/OFF/AUTO control are included for each pump
• Auxiliary output dry contacts (NO-COM-NC) terminals, Form C, 5A resistive load
• Pump Run dry contact, (NO-COM)
• Control circuit powered by 120VAC, 60 Hz
• Alarm circuit can be powered by separate power feed, if needed
• Alarm and control circuits individually fused, 3A, fast-acting, 120VAC
• Circuit breaker protection
• Max alarm and control circuit power consumption: Simplex models 32W
• Max standby power consumption: 5W
• Terminals for 120VAC control power, 120VAC alarm power
• 4 enclosure mounting brackets are included
• All components are serviceable
• All wires and terminal locations thoroughly labeled for easy identification
• cCSAus certified to standard UL508
• FCC Class-B certification to ISED Canada ICES-003, Issue 6
• 5 year limited warranty
