Zoeller Pump Company - 31324-0001 - Control,Pivot/Sim/1Ph/115/200/230V/7-15FLA/Standard

This single phase control panel is used on a simplex pump application where automatic electrical cycling of the pump is desired for added protection in residential or commercial applications. All electrical systems must be installed by a qualified electrician and according to the National Electrical Code.

This control panel can be used with Zoeller pumps:

            N53     N55     N57     N59     N98

            N137   N139   N140   N145   N152   N153

            I161     E161    I163     E163    I165     E165

            I185     E185    E186    E188    E191

            N266   N267   E270    N282    I284     E284

            I292     E292    I293     E293    E294

            I404     E404

            N803   N805   N807   N818

            I818     I819     E819    E820

Features

• NEMA 4X, 12" x 10" x 6" with lockable
• For outdoor or indoor use
• Red alarm beacon with 360-degree visibility
• Audible alarm buzzer rated 95 db at 2ft (0.6 m)
• SILENCE/RESET/TEST toggle switch with weatherproof rubber boot
• HAND/OFF/AUTO control are included for each pump
• Auxiliary output dry contacts (NO-COM-NC) terminals, Form C, 5A resistive load
• Pump Run dry contact, (NO-COM)
• Control circuit powered by 120VAC, 60 Hz
• Alarm circuit can be powered by separate power feed, if needed
• Alarm and control circuits individually fused, 3A, fast-acting, 120VAC
• Circuit breaker protection
• Max alarm and control circuit power consumption: Simplex models 32W
• Max standby power consumption: 5W
• Terminals for 120VAC control power, 120VAC alarm power
• 4 enclosure mounting brackets are included
• All components are serviceable
• All wires and terminal locations thoroughly labeled for easy identification
• cCSAus certified to standard UL508
• FCC Class-B certification to ISED Canada ICES-003, Issue 6
• 5 year limited warranty
