Zoeller Pump Company - 31-0159 - Basin,P-S/18X30/2V2D/(1)4"Psl/10'Stack

Zoeller Pump Company - 31-0159 - Basin,P-S/18X30/2V2D/(1)4"Psl/10'Stack

Package includes:

• Basin, Part# 31-0158
• Cover, Part# 17-0080

Features

• 18" diameter
• 2" vent, 2" discharge
• Durable steel - solid cover
• Sewage basins are watertight and gas tight when properly installed
• Passes the 10 feet water stack test - allows basin to withstand water pressure from a 10 ft. vertical pipe (stack) without leaking
• Durable steel cover with gasket standard on simplex and duplex sewage basins
• Basin and cover are IAPMO listed
• One piece, seam free construction on all basins
• Ready to install for economical and simple installation
• Temperature rated 130°F
• Includes a 4" pipe seal grommet seal inlet hub (for curved or flat surfaces) that fits 4" galvanized steel pipe or Schedule 40 or SDR 35 plastic pipe.  For 4" cast iron hub, use part number 005198.

Basins are not designed to be installed where saturated soil hydrostatic pressure extends above the top of the pit unless the pressure is relieved by an independent drainage system.

Note: Photo is illustrative and may not reflect the actual product.
