Flomatic Valves - 2254STR - Model 402BT / 402BTR 24"

Flomatic Valves

402BT/402BTR/402ST/402STR - Epoxy coated ductile iron silent check globe style, body design for use with class 150 flanges. Unleaded bronze metal to metal seating 2" - 12" sizes. Stainless Steel trim and resilient seat standard on 16", 20", 24" sizes (STR Models). Available on other sizes optional, see note below.

Ductile Iron 2" - 12" - Max Pressure 300 PSI at 150°F
Ductile Iron 14" ,16", 20", 24" - Max Pressure 250 PSI at 150°F
Cast Iron 18"- Max Pressure 150 PSI at 150°F
Consult factory for pressure rating standards.

Note: For drip tight EPDM seal, add "R" to end of part number and 10% to list price.

NSF/ANSI 61 and 372 approved. 2" -12" ONLY
